YX-18650-15T

  • YX-18650-15T
  • YX-18650-15T
  • LFP battery>YX-18650-15T
  • LFP battery>YX-18650-15T
Part number YX-18650-15T
Product classification 84
Manufacturer
Description CE/UN38.3
Encapsulation -
Quantity 1000
RoHS status YES
Share
Price $
IN STOCK: 1000
Total number

Quantity

Price

Total price

Obtain quotation information
Product parameters
Application: Electric Vehicles, Power Tools, Solar Energy Storage, Medical Devices Charging Time: 8 Hours (standard Charge)
Safety Features: Overcharge Protection, Overdischarge Protection, Short Circuit Protection Model No.: YX18650-15T
Voltage: 3.7V Typical Capacity: 1530mAh
High Light:

3.7V High Discharge Lithium Battery Cell, Cylindrical Rechargeable 18650 Cell, 1500mah High Discharge Lithium Battery Cell



Hot Sales li-ion batteries 18650 3.7v 1500mAh with 15C discharge Rechargeable Cylindrical Li-ion Battery



Applications:
Electric Propelling Applications
♦ Engine Starting Battery
♦ Commercial Bus and Transit:
E-car, E-bus, Golf troller/car, E-bike, Scooter, RV, AGV, Marine, Tourist car, Caravan, Wheel chair,
E-truck, E-sweeper, Floor cleaner, E-walker etc.
♦ Intellectual Robots
♦ Power tools: electric drills, toys

Energy Storage
♦ Solar-Wind Power System
♦ City Grid

Back-up System and UPS
♦ Telcom Base, CATV system, Computer Server Center, Medical Instrumnt, Military Equipment

Features:
* Long service life.
* Low self-discharge.
* Environment friendly.
* Good safety performance.
*Broad operating temperature range.



No. Item Specifications
1 Model No. YX18650-15T
2 Typical Capacity 1530mAh @0.2C Discharge
3 Min capacity 1500mAh @0.2C Discharge
4 Nominal voltage 3.7V
5 Standard Charge CC/CV,0.2C,4.20V
6 Standard Discharge CC,02C,3.0V
7 Cut-off charge Voltage 4.20V±0.05V
8 Cut-off charge Current 0.02C(At CVmode)
9 Cut-off discharge Voltage 3.0V
10 Charging Time 8hours(standard charge)
11 Quick Charge Current 1500mA(1C)
12 Quick Discharge Current 1500mA(1C)
13 Max Discharge Current 22500mA (15C)
14 Initial Impedance ≤18mΩ
15 Weight 40.2±2g
16 Operating temperature Charging: 0℃~45℃
Discharging:-20℃~60℃
17 Storage temperature -5℃~35℃
18 Storage Humidity ≤75%RH
19 Standard environmental condition Temperature:25±2℃
Humidity:45-75%RH
Atmospheric Pressure:86-106KPA
