YX14500-600

Typical Capacity: 600mAh, 0.2C discharge

Nominal Voltage: 3.7V

Standard Charge: CC/CV, 0.2C, 4.20V

Standard Discharge: CC, 0.2C, 3.00V

Charge Termination Voltage: 4.20V±0.05V

Charge Termination Current: 0.02C (At CV mode)

Discharge Termination Voltage: 3.00V

Charge Time: 8 hours

Initial Internal Resistance: Max: 70mΩ

Weight: 20.2±2g

Operating Temperature: Charging 0℃~45℃; Discharging -20℃~60℃

Storage Temperature: -5℃~35℃

Storage Humidity: ≤75% RH
