YX-18650-20T

  • YX-18650-20T
  • YX-18650-20T
  • LFP battery>YX-18650-20T
  • LFP battery>YX-18650-20T
Part number YX-18650-20T
Product classification 84
Manufacturer
Description CE/UN38.3
Encapsulation -
Quantity 1000
RoHS status YES
Share
Price $
IN STOCK: 1000
Total number

Quantity

Price

Total price

Obtain quotation information
Product parameters
Application: Portable Electronic Devices, Power Tools, Electric Vehicles Certifications: CE, RoHS, UL
Charging Temperature: 0°C To 50°C Cycle Life: 500 Cycles
    Operating Temperature: -20°C To 75°C
Voltage: 3.7V
High Light:

Safety Cylindrical Lithium Ion Cell, Safety 18650 Lithium Battery Cell, 3.7V Cylindrical Lithium Ion Cell





Hot Sales li-ion batteries 18650 3.7v 2000mah with 15C discharge lithium Battery 3.7v Cylinder Rechargeable Battery for EV-car



Applications:
Electric Propelling Applications
♦ Engine Starting Battery
♦ Commercial Bus and Transit:
E-car, E-bus, Golf troller/car, E-bike, Scooter, RV, AGV, Marine, Tourist car, Caravan, Wheel chair,
E-truck, E-sweeper, Floor cleaner, E-walker etc.
♦ Intellectual Robots
♦ Power tools: electric drills, toys

Energy Storage
♦ Solar-Wind Power System
♦ City Grid

Back-up System and UPS
♦ Telcom Base, CATV system, Computer Server Center, Medical Instrumnt, Military Equipment

Features:
* Long service life.
* Low self-discharge.
* Environment friendly.
* Good safety performance.
*Broad operating temperature range.

No. Item Specifications
1 Model No. YX18650-20T
2 Typical Capacity 2000mAh @0.2C Discharge
3 Min capacity 1950mAh @0.2C Discharge
4 Nominal voltage 3.7V
5 Standard Charge CC/CV,0.5C,4.20V
6 Standard Discharge CC,02C,2.5V
7 Cut-off charge Voltage 4.20V±0.05V
8 Cut-off charge Current 100mA (At CVmode)
9 Cut-off discharge Voltage 2.5V
10 Charging Time 3hours(standard charge)
11 Quick Charge Current 6A (3C )
12 Quick Discharge Current 30A (15C )
13 Max Discharge Current 50A (2s)
14 Initial Impedance ≤18mΩ
15 Weight 45g
16 Operating temperature Charging: 0~50
Discharging:-20~75
17 Storage temperature -20~45
18 Storage Humidity ≤75%RH
19 Standard environmental condition Temperature:25±2
Humidity:45-75%RH
Atmospheric Pressure:86-106KPA

CE/UN38.3/RoHS/MSDS
