| Application: | Electric Vehicles, Power Tools, Solar Energy Storage, Medical Devices | Charging Time: | 8 Hours (standard Charge) |
|---|---|---|---|
| Safety Features: | Overcharge Protection, Overdischarge Protection, Short Circuit Protection | Model No.: | YX18650-15T |
| Voltage: | 3.7V | Typical Capacity: | 1530mAh |
| High Light: |
3.7V High Discharge Lithium Battery Cell, Cylindrical Rechargeable 18650 Cell, 1500mah High Discharge Lithium Battery Cell |
||
Hot Sales li-ion batteries 18650 3.7v 1500mAh with 15C discharge Rechargeable Cylindrical Li-ion Battery
Applications:
Electric Propelling Applications
♦ Engine Starting Battery
♦ Commercial Bus and Transit:
E-car, E-bus, Golf troller/car, E-bike, Scooter, RV, AGV, Marine, Tourist car, Caravan, Wheel chair,
E-truck, E-sweeper, Floor cleaner, E-walker etc.
♦ Intellectual Robots
♦ Power tools: electric drills, toys
Energy Storage
♦ Solar-Wind Power System
♦ City Grid
Back-up System and UPS
♦ Telcom Base, CATV system, Computer Server Center, Medical Instrumnt, Military Equipment
Features:
* Long service life.
* Low self-discharge.
* Environment friendly.
* Good safety performance.
*Broad operating temperature range.
| No. | Item | Specifications |
| 1 | Model No. | YX18650-15T |
| 2 | Typical Capacity | 1530mAh @0.2C Discharge |
| 3 | Min capacity | 1500mAh @0.2C Discharge |
| 4 | Nominal voltage | 3.7V |
| 5 | Standard Charge | CC/CV,0.2C,4.20V |
| 6 | Standard Discharge | CC,02C,3.0V |
| 7 | Cut-off charge Voltage | 4.20V±0.05V |
| 8 | Cut-off charge Current | 0.02C(At CVmode) |
| 9 | Cut-off discharge Voltage | 3.0V |
| 10 | Charging Time | 8hours(standard charge) |
| 11 | Quick Charge Current | 1500mA(1C) |
| 12 | Quick Discharge Current | 1500mA(1C) |
| 13 | Max Discharge Current | 22500mA (15C) |
| 14 | Initial Impedance | ≤18mΩ |
| 15 | Weight | 40.2±2g |
| 16 | Operating temperature | Charging: 0℃~45℃ Discharging:-20℃~60℃ |
| 17 | Storage temperature | -5℃~35℃ |
| 18 | Storage Humidity | ≤75%RH |
| 19 | Standard environmental condition | Temperature:25±2℃ Humidity:45-75%RH Atmospheric Pressure:86-106KPA |
