| Model No.: | YX-IFR26650 | Rated Voltage: | 3.2V |
|---|---|---|---|
| Rated Capacity: | 4000mAh | Max Discharge Current: | 12000mA(3C) |
| Max Charge Current: | 4000mAh(1C) | Net Weight: | 92g |
| High Light: |
3C discharge LFP 26650 battery cell, 3.2V LFP 26650 battery cell, 4000mAh LFP 26650 battery cell |
||
| No. | Item | Specifications |
| 1 | Model No. | YX-IFR26650 |
| 2 | Typical Capacity | 4000mAh @0.2C Discharge |
| 3 | Min Capacity | 3950mAh @0.2C Discharge |
| 4 | Nominal voltage | 3.2V |
| 5 | Standard Charge | CC/CV,0.2C,3.65V |
| 6 | Standard Discharge | CC,02C,2.0V |
| 7 | Cut-off charge voltage | 3.65V±0.03V |
| 8 | Cut-off charge Current | 0.02C(At CV mode) |
| 9 | Cut-off discharge Voltage | 2.0V |
| 10 | Charging Time | 8.0hours(standard charge) |
| 11 | Quick Charge Current | 4000mAh(1C) |
| 12 | Quick Discharge Current | 4000mAh(1C) |
| 13 | Max Discharge Current | 12000mA(3C) |
| 14 | Initial Impedance | ≤25mΩ |
| 15 | Weight | 92±2g |
| 16 | Operating temperature | Charging:0℃-45℃ Discharging:-20℃-60℃ |
| 17 | Storage temperature | -20℃-45℃ |
| 18 | Storage Humidity | ≤75%RH |
| 19 | Standard environmental condition | Temperature:25±2℃ Humidity:45-75%RH Atmospheric Pressure:86-106 KPA |
